Transportable Fuel Tank Rentals

When your fuel needs to move with the job, Taylor Oil rents the Western Global TransCube Global across the Boston to DC corridor. It is a transportable, double-walled fuel storage tank that keeps equipment running on remote sites, between projects, and anywhere a stationary tank cannot follow the work.

The difference with a transportable tank is that you can move it full. Four-way fork pockets and full-load lifting eyes let you reposition the TransCube from one part of a site to the next, or haul it to the next project, without draining it first. On site, it fuels up to three pieces of equipment at once, so your crew spends less time waiting on fuel and more time working.

Every TransCube ships with pre-installed accessories, 110% double-walled containment that removes the need for spill pans or basins, and a lockable cabinet that protects fuel and ports. It is recognized for safe fuel storage and transport under UN-IBC, USDOT, and Transport Canada standards, and it carries an industry-leading 8-year tank warranty.

Call Taylor Oil to reserve a TransCube that fits your operation.

Western Global TransCube Global: Fuel That Travels With the Job

The TransCube Global extends equipment run times and refuels multiple machines at once to save you time and money. It is built for onsite fleet refueling, extended runtime, and auxiliary supply, and it holds up on remote and mega job sites, in mining, and in disaster relief where dependable fuel matters most.

Why the TransCube Global

  • Transportable. UN-IBC, USDOT, and Transport Canada recognized for safe fuel storage and transport.
  • Ready to move full. Four-way fork pockets and full-load lifting eyes allow transport while full of fuel, in accordance with UN-IBC approval.
  • 110% contained. Built-in double-walled containment eliminates spill pans and basins.
  • Turnkey. Arrives onsite with accessories pre-installed and ready to run.
  • Secure. A lockable equipment cabinet protects fuel, ports, and equipment.
  • Guaranteed. Backed by an industry-leading 8-year tank warranty.

Application Uses

Onsite fleet refueling, remote and mega job sites, extended runtime, generators, pumps, heaters, disaster relief, and mining.

Models and Specifications



10TCG

20TCG

30TCG

40TCG

50TCG

Brim Fill

251 USG / 949 L

552 USG / 2,091 L

787 USG / 2,980 L

1,000 USG / 3,785 L

1,215 USG / 4,600 L

95% Safe Fill

238 USG / 902 L

525 USG / 1,986 L

748 USG / 2,831 L

950 USG / 3,596 L

1,154 USG / 4,370 L

Weight (empty)

1,190 lbs / 540 kg

1,814 lbs / 823 kg

2,425 lbs / 1,100 kg

3,483 lbs / 1,580 kg

3,726 lbs / 1,690 kg

Weight (full)

3,178 lbs / 1,442 kg

6,194 lbs / 2,809 kg

8,666 lbs / 3,931 kg

11,839 lbs / 5,370 kg

13,889 lbs / 6,300 kg

Dimensions (L x W x H)

45 x 45 x 52 in

90 x 45 x 52 in

90 x 61 x 52 in

92 x 92 x 45 in

92 x 92 x 52 in

Tank Approvals and Standards

Transport: USDOT, Transport Canada, UN IBC 31A/Y. Stationary: UL142, CAN/ULC-S601, NFPA 30. UL listing does not cover use while in transport or optional accessories.

Call Taylor Oil now to reserve your Western Global TransCube Global. We have the capacity to fit any requirement.
